The Rich Solar MEGA 400 24 V panel delivers 400 watts of dependable solar power for off-grid or grid-tie systems. Designed for homes, farms, cabins, and commercial setups, it combines high-efficiency cells, a durable anodized aluminum frame, and tempered glass for long-lasting performance in any climate. Backed by a 25-year output warranty and UL certification for proven reliability.
NOTICE: The new 400w panels have the following dimensions: 67.9 x 44.6 x 1.2 in
Features
- 10-busbar solar cell configuration
- Mono PERC Technology
- Lightweight anodized aluminum frame
- High-transmission, AR (anti-reflective) Coated Tempered Glass
- Plug-and-play junction box
- Industry-standard quick-connect cables work in series or parallel
- Certified to withstand challenging environmental conditions
- Excellent low-light performance on cloudy days, mornings, and evenings
Installation
- Easy installation and handling for various applications (high-end off-grid and mobile applications)
- Pre-drilled holes compatible with ground mounts, Z brackets, pole mounts, and tilt mounts
- Compatible with on-grid and off-grid inverters
Warranty
- 25-year limited power output warranty
- 10-year workmanship warranty
Specifications
-
Panel Cable Length: ≈ 47 in
-
Material: Tempered Glass, Aluminum, Monocrystalline Silicon
-
Dimensions: 67.9 x 44.7 x 1.2 in
-
Weight: 45.2 lbs
-
Maximum Power (PMAX): 400W
-
Maximum Power Voltage (VMP): 31.0V
-
Maximum Power Current (IMP): 12.9A
-
Open Circuit Voltage (VOC): 37.1V
-
Short Circuit Current (ISC): 13.7A
-
Maximum System Voltage (VMAX): 1500VDC
-
Temperature Range: -40 ~ +185°F
-
Maximum Series Fuse Rating: 25A
