The Rich Solar MEGA 410 delivers 410 watts of premium solar power for homes, cabins, farms, RVs, and commercial systems. Designed for grid-tie, off-grid, and hybrid setups, it maximizes output while minimizing space and installation costs.
Built with a durable anodized aluminum frame and tempered glass, the MEGA 410 is UL certified and backed by a 25-year output warranty, ensuring long-lasting, reliable performance in any environment.
Features
- 10-busbar solar cell configuration
- Mono PERC Technology
- Lightweight anodized aluminum frame
- High Transmission, AR (anti-reflective) Coated Tempered Glass
- Plug-and-play junction box
- Industry-standard quick-connect cables work in series or parallel
- Certified to withstand challenging environmental conditions
- Excellent low-light performance on cloudy days, mornings, and evenings
Installation
- Easy installation and handling for various applications (high-end off-grid and mobile applications)
- Pre-drilled holes compatible with ground mounts, Z brackets, pole mounts, and tilt mounts
- Compatible with on-grid and off-grid inverters
Warranty
- 25-year limited power output warranty
- 10-year workmanship warranty
Built-in Components
- Panel leads (pair): 4 feet each
- IP68-rated waterproof junction box
- IP67-rated waterproof solar connectors
- Bypass diodes built into the junction box
Specifications
-
Maximum Power(Pmax): 410W
-
Maximum Power Voltage(Vmp): 31.3V
-
Maximum Power Current(Imp): 13.1A
-
Open Circuit Voltage(Voc): 37.5V
-
Short Circuit Current(Isc): 13.8A
-
Maximum System Voltage(Vmax): 1500VDC
-
Temperature Range: -40°F ~ 185°F
-
Max Series Fuse Rating: 25A
-
Weight: 45.2 lb
-
Dimensions: 67.9 x 44.7 x 1.2 in
